Feature

• 32-bit STM32 F722 main controller for stable and powerful processing
• High-precision ICM42688P gyro for smooth attitude control
• Dual BEC output: 5V/3A + 12V/2A to power cameras, VTX, receivers and other peripherals
• 5 UART ports for flexible connection with GPS, receiver, VTX, HD unit and more
• 16MB Blackbox for flight data recording and tuning
• Built-in barometer support for altitude hold and return-to-home functions
• Supports both analog VTX (IRC Tramp) and HD digital systems (DJI O3, Avatar HD, Vista/Link)
• Standard 30.5×30.5mm mounting hole spacing for universal stack compatibility

Recommended Configuration

• Model: Argus ECO FC F722
• Input Voltage: 4–8S LiPo
• Mount: 30.5×30.5mm (M3)
• Application: 5–7 inch freestyle / long-range / cinematic FPV drones

Specifications

• Model: Argus ECO FC F722
• Firmware Name: SPEDIX F722
• MCU: STM32 F722
• Gyro: ICM42688P
• Blackbox: 16M
• Barometer: Supported
• Input Voltage: 4–8S LiPo
• BEC Output: 5V/3A + 12V/2A
• UART Ports: 5 sets
• OSD: Supported
• Size: 36×36×6mm
• Install Hole Distance: 30.5×30.5mm
• Weight: 7g

Package Contents

1. Argus ECO FC F722 ×1
2. Mounting screws and damping grommets set ×1
3. Connection cables for receiver, camera and VTX ×1 set
